Field fence

Material
Iron wire, steel wire

Popular size
8/120/15/100
10/120/15/100
10/120/30/100
16/180/15/100
16/180/30/100
Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
sharethis sharing button

Product Description

Field fence have innovative and firm structure, flat surface, uniform opening and good integration. This product offers good flexibility, pressure resistance, corrosion resistance and weather resistance properties and can serve for a very long time. Even the cut pieces will not deform under pressure. It has excellent corrosion resistance and anti-oxidizing property. Our field fences are firm forever once installed and make the best materials for protecting grassland, animal, forestry, highway and environments.



Three types of field fence

Hinge knot

S knot

Fixed knot


Specification Sheet


No.


Type


Specifications and hole sizes

Weight ( KG)


Top and bottom wire diameter (mm)


Inner wire diameter (mm)


Specifications (the incremental vertical hole sizes)

1

7/150/813/50

102+104+127+140+152+178

19.3

2.5

2

2

8/150/813/50

89(75)+89+102+114+127+140+ 152

20.8

2.5

2

3

8/150/902/50

89+102+114+127+140+152+178

21.6

2.5

2

4

8/150/1016/50

102+114+127+140+152+178+203

22.6

2.5

2

5

8/150/1143/50

114+127+140+152+178+203+229

23.6

2.5

2

6

9/150/991/50

89(75)+89+102+114+127+140+152+178

23.9

2.5

2

7

9/150/1245/50

102+114+127+140+152+178+203+229

26

2.5

2

8

10/150/1194/50

89(75)+89+102+114+127+140+152+178+203

27.3

2.5

2

9

10/150/1334/50

89+102+114+127+152+178+203+223

28.4

2.5

2

10

11/150/1422/50

89(75)+89+102+114+127+140+152+178+203+229

30.8

2.5

2
